Szczegóły Produktu:
|
|
Miejsce pochodzenia: | CHINY |
---|---|
Nazwa handlowa: | Glawall |
Orzecznictwo: | SGS, ISO 9001,UL, CE |
Numer modelu: | W pełni modułowa podwójna szklana ściana |
Dokument: | 25mm.pdf |
Zapłata:
|
|
Minimalne zamówienie: | 10 Kwadratowych Materów |
Cena: | US$80.00 10 - 99 square meters |
Szczegóły pakowania: | sklejka |
Czas dostawy: | 20-25 dni |
Zasady płatności: | L/C, D/A, D/P, T/T, ZARZĄDENIE WESTOLA |
Możliwość Supply: | 3000 metrów kwadratowych miesięcznie |
Szczegóły informacji |
|||
Korzyść: | Konkurencyjna cena, dobra obsługa, wysoki profesjonalizm, gwarancja jakości | Miejsce Origi: | Guangdong, Chiny |
---|---|---|---|
Certyfikacja fabryczna: | Tak | Teren fabryki: | 20 000 metrów kwadratowych |
Tworzywo: | Rama aluminiowa, panele akustyczne | Soundproofing: | 38-45dB |
Grubość panelu: | 60, 90.108 mm | Typ szkła: | mocne, hartowane szkło |
Wentylacja: | System przepływu powietrza | Gwarancja: | 2 lata |
Podkreślić: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system |
opis produktu
Advantage | Competitive price, good service, high professional, quality guarantee |
Place of Origin | Guangdong, China |
Factory Certification | Yes |
Factory Area | 20000 square meter |
Material | Aluminum Frame, Acoustic Panels |
Soundproofing | 38-45dB |
Panel Thickness | 60, 90, 108mm |
Glass Type | Strong tempered glass |
Ventilation | Airflow System |
Warranty | 2 Years |
Feature | Benefit |
---|---|
Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
Tool-Free Connection | Patented click-lock system secures panels without tools |
Fast Installation | 2-person team can install 20m² in under 3 hours |
42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
Step | Action |
---|---|
Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
Step 3 | Snap decorative covers over joints for perfect alignment |
Feature | Specification |
---|---|
Frame | 90mm powder-coated aluminum (20+ RAL colors) |
Glass | 5+5mm tempered (clear/frosted/tinted options) |
Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
Fire Rating | EI30-EI60 available |
Max Height | 4m without additional support |
For Contractors | For Clients |
---|---|
70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
